SEAL 36
• Designed by E. G. van de Stadt
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
Steel Alum. or Wood
First Built:
1976
Dimensions
Length Overall (LOA):
11.00 m
Length Waterline (LWL):
8.70 m
Beam:
3.54 m
Draft (Max):
1.90 m
Headroom:
1.52 m
Max Height:
15.90 m
Weight & Ballast
Displacement:
9,250 kg
Ballast:
3,300 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
34.08 m²
Mainsail Area:
24.19 m²
Total Sail Area (calculated):
58.27 m²
Sail Area (reported):
78.97 m²
I (Fore Triangle Height):
14.50 m
J (Fore Triangle Base):
4.70 m
P (Mainsail Hoist):
12.90 m
E (Boom Length):
3.75 m
Engine & Systems
Engine Type:
Diesel
Engine Power:
25 HP
Fuel Capacity:
300 L
Water Capacity:
460 L
Performance Ratios
Hull Speed:
7.16 knots
SA/Displacement (Calculated):
13.22
SA/Displacement (Reported):
18.29
Ballast/Disp Ratio:
35.67%
Displacement/Length:
391.63
Comfort Ratio:
39.06
Capsize Screening:
1.70
S-Number:
0.98
Notes
Van de Stadt design #260
