SANTANA 30-30PC
Built by W. D. Schock Corp.(USA)
• Designed by Nelson/Marek
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1981
Number Built:
40
Dimensions
Length Overall (LOA):
9.12 m
Length Waterline (LWL):
7.75 m
Beam:
3.12 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
2,948 kg
Ballast:
1,048 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
22.17 m²
Mainsail Area:
18.67 m²
Total Sail Area (calculated):
40.84 m²
Sail Area (reported):
40.88 m²
I (Fore Triangle Height):
12.44 m
J (Fore Triangle Base):
3.57 m
P (Mainsail Hoist):
11.03 m
E (Boom Length):
3.38 m
Engine & Systems
Performance Ratios
Hull Speed:
6.76 knots
SA/Displacement (Calculated):
19.86
SA/Displacement (Reported):
20.28
Ballast/Disp Ratio:
35.54%
Displacement/Length:
176.66
Comfort Ratio:
16.91
Capsize Screening:
2.20
S-Number:
3.40
Notes
The Santana 30-30 was designed to the MORC rule.
