SANTANA 27
Built by W. D. Schock Corp. (USA)
• Designed by Gary Mull
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1967
Last Built:
1974
Number Built:
210
Dimensions
Length Overall (LOA):
8.24 m
Length Waterline (LWL):
6.86 m
Beam:
2.74 m
Draft (Max):
1.30 m
Weight & Ballast
Displacement:
2,268 kg
Ballast:
1,043 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
17.64 m²
Mainsail Area:
14.69 m²
Total Sail Area (calculated):
32.33 m²
Sail Area (reported):
32.33 m²
I (Fore Triangle Height):
10.29 m
J (Fore Triangle Base):
3.43 m
P (Mainsail Hoist):
8.38 m
E (Boom Length):
3.51 m
Engine & Systems
Performance Ratios
Hull Speed:
6.36 knots
SA/Displacement (Calculated):
18.73
SA/Displacement (Reported):
19.10
Ballast/Disp Ratio:
46.00%
Displacement/Length:
195.96
Comfort Ratio:
17.35
Capsize Screening:
2.11
S-Number:
3.00
