SANTANA 2023A
Built by W. D. Schock Corp.(USA)
• Designed by Steven Schock/Shad Turner
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Centerboard (Trunk)
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1993
Last Built:
2002
Dimensions
Length Overall (LOA):
7.11 m
Length Waterline (LWL):
6.28 m
Beam:
2.59 m
Draft (Max):
1.62 m
Draft (Min):
0.36 m
Weight & Ballast
Displacement:
1,306 kg
Ballast:
590 kg
Ballast Type:
Water
Sail Plan
Sail Area (reported):
21.74 m²
Engine & Systems
Performance Ratios
Hull Speed:
6.08 knots
SA/Displacement (Reported):
18.54
Ballast/Disp Ratio:
45.14%
Displacement/Length:
146.65
Comfort Ratio:
12.00
Capsize Screening:
2.39
Notes
Based, in part, on the Shad Turner designed SANTANA 23 D (1978), but capable of carrying 1300 lbs. of water ballast. (primarily to reduce trailering weight.)
