SAN JUAN 7.7
Built by Clark Boat Co. (USA)
• Designed by Don Clark
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1979
Dimensions
Length Overall (LOA):
7.85 m
Length Waterline (LWL):
6.10 m
Beam:
2.90 m
Draft (Max):
1.22 m
Weight & Ballast
Displacement:
1,451 kg
Ballast:
499 kg
Sail Plan
Foresail Area:
12.25 m²
Mainsail Area:
15.33 m²
Total Sail Area (calculated):
27.58 m²
Sail Area (reported):
28.24 m²
I (Fore Triangle Height):
8.46 m
J (Fore Triangle Base):
2.90 m
P (Mainsail Hoist):
9.14 m
E (Boom Length):
3.35 m
Engine & Systems
Performance Ratios
Hull Speed:
5.99 knots
SA/Displacement (Calculated):
21.51
SA/Displacement (Reported):
22.46
Ballast/Disp Ratio:
34.38%
Displacement/Length:
178.57
Comfort Ratio:
11.35
Capsize Screening:
2.58
S-Number:
3.56
Notes
The SJ7.7 replaced the SJ 26 in 1979. Intitially this boat was called the SAN JUAN 26 PC.
