SAN JUAN 24
Built by Clark Boat Co. (USA)
• Designed by Bruce Kirby
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1973
Number Built:
1200
Dimensions
Length Overall (LOA):
7.32 m
Length Waterline (LWL):
5.94 m
Beam:
2.44 m
Draft (Max):
1.22 m
Weight & Ballast
Displacement:
1,451 kg
Ballast:
748 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
13.24 m²
Mainsail Area:
9.66 m²
Total Sail Area (calculated):
22.90 m²
Sail Area (reported):
22.85 m²
I (Fore Triangle Height):
9.14 m
J (Fore Triangle Base):
2.90 m
P (Mainsail Hoist):
7.92 m
E (Boom Length):
2.44 m
Engine & Systems
Performance Ratios
Hull Speed:
5.92 knots
SA/Displacement (Calculated):
17.87
SA/Displacement (Reported):
18.17
Ballast/Disp Ratio:
51.56%
Displacement/Length:
192.66
Comfort Ratio:
14.86
Capsize Screening:
2.17
S-Number:
2.94
Notes
From IOR 1/4 ton prototype.
