SAN JUAN 23
Built by Clark Boat Co. (USA)
• Designed by B.Kirby/Clark
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1975
Dimensions
Length Overall (LOA):
7.01 m
Length Waterline (LWL):
6.20 m
Beam:
2.44 m
Draft (Max):
1.45 m
Draft (Min):
0.59 m
Weight & Ballast
Displacement:
1,225 kg
Ballast:
435 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
12.36 m²
Mainsail Area:
9.75 m²
Total Sail Area (calculated):
22.11 m²
Sail Area (reported):
21.74 m²
I (Fore Triangle Height):
8.53 m
J (Fore Triangle Base):
2.90 m
P (Mainsail Hoist):
7.32 m
E (Boom Length):
2.67 m
Engine & Systems
Performance Ratios
Hull Speed:
6.04 knots
SA/Displacement (Calculated):
19.31
SA/Displacement (Reported):
19.36
Ballast/Disp Ratio:
35.56%
Displacement/Length:
143.45
Comfort Ratio:
12.37
Capsize Screening:
2.30
S-Number:
3.85
Notes
The SAN JUAN 23 derived from the more racing oriented SAN JUAN 24. This same design was also built in Australia for a time as the WINDWARD 7 and in New Zealand as the FLEETWOOD 25.
