SAMOURAI MK1
Built by CNSO (FRA)
• Designed by Michel Bigoin/Daniel Duvergie
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1968
Last Built:
1970
Number Built:
800
Dimensions
Length Overall (LOA):
7.40 m
Length Waterline (LWL):
5.80 m
Beam:
2.40 m
Draft (Max):
1.20 m
Weight & Ballast
Displacement:
1,600 kg
Ballast:
700 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
12.61 m²
Mainsail Area:
10.80 m²
Total Sail Area (calculated):
23.41 m²
Sail Area (reported):
23.41 m²
I (Fore Triangle Height):
9.00 m
J (Fore Triangle Base):
2.80 m
P (Mainsail Hoist):
8.00 m
E (Boom Length):
2.70 m
Engine & Systems
Performance Ratios
Hull Speed:
5.85 knots
SA/Displacement (Calculated):
17.11
SA/Displacement (Reported):
17.45
Ballast/Disp Ratio:
43.75%
Displacement/Length:
228.48
Comfort Ratio:
16.94
Capsize Screening:
2.07
S-Number:
2.44
Notes
There are two types of Samouraïs, the MK1 (7m40) and the MK2 (7m60).
