SAGITTA 30
Built by Royal System Yacht Yard (DEN)
• Designed by Aage Utzon
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1963
Last Built:
1991
Number Built:
40
Dimensions
Length Overall (LOA):
9.15 m
Length Waterline (LWL):
7.34 m
Beam:
2.74 m
Draft (Max):
1.45 m
Weight & Ballast
Displacement:
4,200 kg
Ballast:
1,860 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
21.02 m²
Mainsail Area:
14.56 m²
Total Sail Area (calculated):
35.58 m²
Sail Area (reported):
35.58 m²
I (Fore Triangle Height):
11.13 m
J (Fore Triangle Base):
3.78 m
P (Mainsail Hoist):
10.06 m
E (Boom Length):
2.90 m
Engine & Systems
Engine Make:
Watermota
Engine Type:
Gas
Engine Model:
Sea Panther
Engine Power:
29 HP
Fuel Capacity:
42 L
Water Capacity:
87 L
Performance Ratios
Hull Speed:
6.58 knots
SA/Displacement (Calculated):
13.67
SA/Displacement (Reported):
13.94
Ballast/Disp Ratio:
44.28%
Displacement/Length:
296.07
Comfort Ratio:
29.64
Capsize Screening:
1.72
S-Number:
1.52
Notes
Designed to RORC Class III rule.
