S2 8.0 C
Built by S2 Yachts
• Designed by Arthur Edmunds
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1975
Number Built:
210
Dimensions
Length Overall (LOA):
7.92 m
Length Waterline (LWL):
6.53 m
Beam:
2.44 m
Draft (Max):
1.22 m
Max Height:
10.82 m
Weight & Ballast
Displacement:
2,359 kg
Ballast:
816 kg
Sail Plan
Foresail Area:
16.19 m²
Mainsail Area:
10.91 m²
Total Sail Area (calculated):
27.10 m²
Sail Area (reported):
27.13 m²
I (Fore Triangle Height):
9.24 m
J (Fore Triangle Base):
3.51 m
P (Mainsail Hoist):
7.96 m
E (Boom Length):
2.74 m
Engine & Systems
Performance Ratios
Hull Speed:
6.20 knots
SA/Displacement (Calculated):
15.29
SA/Displacement (Reported):
15.61
Ballast/Disp Ratio:
34.62%
Displacement/Length:
236.21
Comfort Ratio:
22.09
Capsize Screening:
1.85
S-Number:
2.16
Notes
All 8.0 versions had the same hull but with different decks and interiors. The suffix 'C' is for center cockpit.
