S&S 40 (1964)
Built by Teksoglass (SWE)
• Designed by Sparkman & Stephens
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin Keel
Rigging Type:
Masthead Sloop
Construction:
Wood/FG
First Built:
1964
Last Built:
1976
Number Built:
20
Dimensions
Length Overall (LOA):
12.14 m
Length Waterline (LWL):
8.76 m
Beam:
3.05 m
Draft (Max):
1.98 m
Weight & Ballast
Displacement:
7,802 kg
Ballast:
3,175 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
33.47 m²
Mainsail Area:
27.60 m²
Total Sail Area (calculated):
61.07 m²
Sail Area (reported):
61.22 m²
I (Fore Triangle Height):
14.33 m
J (Fore Triangle Base):
4.67 m
P (Mainsail Hoist):
11.74 m
E (Boom Length):
4.70 m
Engine & Systems
Performance Ratios
Hull Speed:
7.18 knots
SA/Displacement (Calculated):
15.52
SA/Displacement (Reported):
15.88
Ballast/Disp Ratio:
40.70%
Displacement/Length:
323.12
Comfort Ratio:
38.59
Capsize Screening:
1.55
S-Number:
1.50
Notes
S&S design #1767.(seems identical to #1738) Successful racer under RORC. From several builders. Various options, conventional or reverse transom; coachroof or flush deck with differing layouts and rigs.
