S&S 30 (AQUAFIBRE)
Built by Aquafibre Ltd, (UK)
• Designed by Sparkman & Stephens
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1972
Dimensions
Length Overall (LOA):
9.17 m
Length Waterline (LWL):
7.01 m
Beam:
2.74 m
Draft (Max):
1.52 m
Weight & Ballast
Displacement:
4,082 kg
Ballast:
1,905 kg
Sail Plan
Foresail Area:
19.90 m²
Mainsail Area:
18.70 m²
Total Sail Area (calculated):
38.60 m²
Sail Area (reported):
38.55 m²
I (Fore Triangle Height):
11.06 m
J (Fore Triangle Base):
3.60 m
P (Mainsail Hoist):
10.67 m
E (Boom Length):
3.51 m
Engine & Systems
Performance Ratios
Hull Speed:
6.43 knots
SA/Displacement (Calculated):
15.11
SA/Displacement (Reported):
15.40
Ballast/Disp Ratio:
46.67%
Displacement/Length:
330.23
Comfort Ratio:
29.65
Capsize Screening:
1.73
S-Number:
1.42
Notes
S&S design #2014. See AQUA 30 for more details.
