RHODES 19 CB
Built by Stuart Marine; O'Day (USA)
• Designed by Philip Rhodes
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Centerboard Dinghy
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1959
Number Built:
3200
Dimensions
Length Overall (LOA):
5.84 m
Length Waterline (LWL):
5.41 m
Beam:
2.13 m
Draft (Max):
1.50 m
Draft (Min):
0.25 m
Max Height:
8.48 m
Weight & Ballast
Displacement:
467 kg
Ballast:
75 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
4.53 m²
Mainsail Area:
11.01 m²
Total Sail Area (calculated):
15.54 m²
Sail Area (reported):
16.26 m²
I (Fore Triangle Height):
4.57 m
J (Fore Triangle Base):
1.98 m
P (Mainsail Hoist):
7.32 m
E (Boom Length):
3.01 m
Engine & Systems
Performance Ratios
Hull Speed:
5.65 knots
SA/Displacement (Calculated):
25.82
SA/Displacement (Reported):
27.50
Ballast/Disp Ratio:
16.02%
Displacement/Length:
82.22
Comfort Ratio:
6.55
Capsize Screening:
2.78
S-Number:
6.14
Notes
Both the RHODES MARINER and the R-19 derived from the HURRICANE, built of molded plywood and sailed around the Chesapeake/LIS area (USA) during the late 1940s. A centerboard RHODES 19 is still available but only the fin keel version is permitted for class one-design racing.
