RHODES 19
Built by Stuart Marine; O'Day (USA)
• Designed by Philip Rhodes
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1959
Number Built:
3200
Dimensions
Length Overall (LOA):
5.84 m
Length Waterline (LWL):
5.41 m
Beam:
2.13 m
Draft (Max):
0.99 m
Weight & Ballast
Displacement:
615 kg
Ballast:
188 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
4.53 m²
Mainsail Area:
11.01 m²
Total Sail Area (calculated):
15.54 m²
Sail Area (reported):
16.26 m²
I (Fore Triangle Height):
4.57 m
J (Fore Triangle Base):
1.98 m
P (Mainsail Hoist):
7.32 m
E (Boom Length):
3.01 m
Engine & Systems
Performance Ratios
Hull Speed:
5.65 knots
SA/Displacement (Calculated):
21.49
SA/Displacement (Reported):
22.91
Ballast/Disp Ratio:
30.63%
Displacement/Length:
108.17
Comfort Ratio:
8.62
Capsize Screening:
2.53
S-Number:
4.85
Notes
The RHODES 19 has it's origins with HURRICANE class (1945) which was a molded plywood centerboarder with an open cockpit built by Allied Aviation Corp. Another builder, Palmer Scott, purchased a number of unfinished HURRICANE hulls, added a foredeck with cuddy cabin, and a fixed keel. This boat was sold as the SMYRNA. It was from the SMYRNA that Marscot Plastics made a plug for a fiberglass version. This was the boat that was later sold by O'Day Corp. as the RHODES 19.
