RELIANCE 12
Built by Reliance Sailing Craft Co., Ltd. (CAN)
• Designed by Steve Killing
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1987
Last Built:
1988
Number Built:
5
Dimensions
Length Overall (LOA):
11.99 m
Length Waterline (LWL):
9.14 m
Beam:
2.54 m
Draft (Max):
1.85 m
Weight & Ballast
Displacement:
4,037 kg
Ballast:
2,268 kg
Sail Plan
Foresail Area:
21.18 m²
Mainsail Area:
24.15 m²
Total Sail Area (calculated):
45.33 m²
Sail Area (reported):
45.34 m²
I (Fore Triangle Height):
11.58 m
J (Fore Triangle Base):
3.66 m
P (Mainsail Hoist):
12.19 m
E (Boom Length):
3.96 m
Engine & Systems
Performance Ratios
Hull Speed:
7.34 knots
SA/Displacement (Calculated):
17.88
SA/Displacement (Reported):
18.24
Ballast/Disp Ratio:
56.18%
Displacement/Length:
147.16
Comfort Ratio:
24.90
Capsize Screening:
1.61
S-Number:
3.59
Notes
A daysailer with the same proportions as a 12 meter (of the 1980's) but scaled down to 40' LOA.
