REDLINE 41 (2014)
Built by US Watercraft (USA)
• Designed by Mark Mills.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
E glass/foam sand.,infusion
First Built:
2014
Dimensions
Length Overall (LOA):
12.41 m
Length Waterline (LWL):
10.79 m
Beam:
3.70 m
Draft (Max):
2.50 m
Weight & Ballast
Displacement:
6,849 kg
Ballast:
3,280 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
38.40 m²
Mainsail Area:
44.38 m²
Total Sail Area (calculated):
82.78 m²
Sail Area (reported):
93.92 m²
I (Fore Triangle Height):
16.25 m
J (Fore Triangle Base):
4.73 m
P (Mainsail Hoist):
16.00 m
E (Boom Length):
5.55 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Power:
40 HP
Fuel Capacity:
148 L
Water Capacity:
265 L
Performance Ratios
Hull Speed:
7.97 knots
SA/Displacement (Calculated):
22.95
SA/Displacement (Reported):
26.57
Ballast/Disp Ratio:
47.89%
Displacement/Length:
151.96
Comfort Ratio:
22.72
Capsize Screening:
1.97
S-Number:
4.19
Notes
Updated version of KING 40 (2001).
