REDLINE 25 (C&C)
Built by Bruckman Manufacturing (CAN)
• Designed by Cuthbertson & Cassian
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1969
Dimensions
Length Overall (LOA):
7.49 m
Length Waterline (LWL):
6.25 m
Beam:
2.44 m
Draft (Max):
1.52 m
Draft (Min):
0.76 m
Weight & Ballast
Displacement:
1,867 kg
Ballast:
868 kg
Sail Plan
Foresail Area:
13.40 m²
Mainsail Area:
10.03 m²
Total Sail Area (calculated):
23.43 m²
Sail Area (reported):
23.41 m²
I (Fore Triangle Height):
8.53 m
J (Fore Triangle Base):
3.14 m
P (Mainsail Hoist):
7.32 m
E (Boom Length):
2.74 m
Engine & Systems
Performance Ratios
Hull Speed:
6.07 knots
SA/Displacement (Calculated):
15.45
SA/Displacement (Reported):
15.75
Ballast/Disp Ratio:
46.51%
Displacement/Length:
213.24
Comfort Ratio:
18.34
Capsize Screening:
2.00
S-Number:
2.41
Notes
Photo courtesy Adam Hunt.
