BB-10
Built by Børresen Bådebyggeri (DEN)
• Designed by Børresen Brothers
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1977
Number Built:
150
Dimensions
Length Overall (LOA):
10.00 m
Length Waterline (LWL):
7.29 m
Beam:
2.30 m
Draft (Max):
1.46 m
Weight & Ballast
Displacement:
2,248 kg
Ballast:
1,225 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
13.73 m²
Mainsail Area:
19.53 m²
Total Sail Area (calculated):
33.26 m²
Sail Area (reported):
32.33 m²
I (Fore Triangle Height):
9.17 m
J (Fore Triangle Base):
2.99 m
P (Mainsail Hoist):
11.00 m
E (Boom Length):
3.55 m
Engine & Systems
Performance Ratios
Hull Speed:
6.55 knots
SA/Displacement (Calculated):
19.38
SA/Displacement (Reported):
19.21
Ballast/Disp Ratio:
54.48%
Displacement/Length:
161.66
Comfort Ratio:
19.50
Capsize Screening:
1.77
S-Number:
3.57
Notes
Spin. area: 63 m2/678 sq ft
