BANNER 28
Built by I.N. FIBERBÅDE (DEN)
• Designed by I. Neilson
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1980
Dimensions
Length Overall (LOA):
8.53 m
Length Waterline (LWL):
6.10 m
Beam:
2.94 m
Draft (Max):
1.34 m
Weight & Ballast
Displacement:
1,157 kg
Ballast:
599 kg
Sail Plan
Foresail Area:
13.56 m²
Mainsail Area:
21.17 m²
Total Sail Area (calculated):
34.73 m²
Sail Area (reported):
34.75 m²
I (Fore Triangle Height):
9.17 m
J (Fore Triangle Base):
2.96 m
P (Mainsail Hoist):
11.67 m
E (Boom Length):
3.63 m
Engine & Systems
Performance Ratios
Hull Speed:
5.99 knots
SA/Displacement (Calculated):
31.51
SA/Displacement (Reported):
32.14
Ballast/Disp Ratio:
51.76%
Displacement/Length:
142.30
Comfort Ratio:
8.59
Capsize Screening:
2.83
S-Number:
5.37
Notes
Designed as IOR 1/2 ton.
