1D 48
Built by Tillotson Pearson (USA)
• Designed by Reichel Pugh Yacht Design
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
Carbon inside/Kevlar ext./SCRIMP
First Built:
1995
Last Built:
1996
Number Built:
8
Dimensions
Length Overall (LOA):
14.76 m
Length Waterline (LWL):
12.47 m
Beam:
4.32 m
Draft (Max):
3.07 m
Weight & Ballast
Displacement:
8,150 kg
Ballast:
4,000 kg
Ballast Type:
Lead + Water
Sail Plan
Foresail Area:
44.93 m²
Mainsail Area:
65.79 m²
Total Sail Area (calculated):
110.72 m²
Sail Area (reported):
110.74 m²
I (Fore Triangle Height):
17.60 m
J (Fore Triangle Base):
5.11 m
P (Mainsail Hoist):
18.77 m
E (Boom Length):
7.01 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3JH2
Engine Power:
21 HP
Fuel Capacity:
83 L
Performance Ratios
Hull Speed:
8.57 knots
SA/Displacement (Calculated):
27.34
SA/Displacement (Reported):
27.91
Ballast/Disp Ratio:
49.08%
Displacement/Length:
117.06
Comfort Ratio:
18.84
Capsize Screening:
2.17
S-Number:
5.48
Notes
1D 48 = ONE DESIGN 48. (A special one design racing circuit for this yacht did exist for at least a year.)
