ARCONA 465
Built by Arcona Yachts
• Designed by Stefan Quiberg
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG Divinycell & Vinyl w carbon
First Built:
2016
Dimensions
Length Overall (LOA):
14.09 m
Length Waterline (LWL):
13.25 m
Beam:
4.24 m
Draft (Max):
2.50 m
Max Height:
22.01 m
Weight & Ballast
Displacement:
9,550 kg
Ballast:
3,800 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
52.89 m²
Mainsail Area:
62.25 m²
Total Sail Area (calculated):
115.14 m²
Sail Area (reported):
115.20 m²
I (Fore Triangle Height):
19.30 m
J (Fore Triangle Base):
5.48 m
P (Mainsail Hoist):
18.50 m
E (Boom Length):
6.73 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
80 HP
Fuel Capacity:
238 L
Water Capacity:
341 L
Performance Ratios
Hull Speed:
8.83 knots
SA/Displacement (Calculated):
25.58
SA/Displacement (Reported):
26.12
Ballast/Disp Ratio:
39.79%
Displacement/Length:
114.42
Comfort Ratio:
22.05
Capsize Screening:
2.02
S-Number:
5.30
Notes
Shallow draft: 7.05'/2.15m
