ARCONA 380/385
Built by Arcona Yachts (SWE)
• Designed by Stefan Qviberg
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
2014
Dimensions
Length Overall (LOA):
11.28 m
Length Waterline (LWL):
10.60 m
Beam:
3.80 m
Draft (Max):
2.10 m
Max Height:
19.51 m
Weight & Ballast
Displacement:
6,850 kg
Ballast:
2,400 kg
Ballast Type:
Cast iron fin with lead bulb
Sail Plan
Foresail Area:
34.02 m²
Mainsail Area:
43.21 m²
Total Sail Area (calculated):
77.23 m²
Sail Area (reported):
77.20 m²
I (Fore Triangle Height):
16.20 m
J (Fore Triangle Base):
4.20 m
P (Mainsail Hoist):
16.00 m
E (Boom Length):
5.40 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3YM30AE saildrive
Engine Power:
29 HP
Fuel Capacity:
136 L
Water Capacity:
201 L
Performance Ratios
Hull Speed:
7.90 knots
SA/Displacement (Calculated):
21.41
SA/Displacement (Reported):
21.84
Ballast/Disp Ratio:
35.04%
Displacement/Length:
160.25
Comfort Ratio:
22.86
Capsize Screening:
2.02
S-Number:
3.85
Notes
Became the 385 in 2020. Same hull and rig as the 380.
