ARCONA 370
Built by Arcona Yachts (SWE)
• Designed by Stefan Qviberg
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
2005
Dimensions
Length Overall (LOA):
11.10 m
Length Waterline (LWL):
10.20 m
Beam:
3.60 m
Draft (Max):
2.05 m
Max Height:
18.50 m
Weight & Ballast
Displacement:
6,200 kg
Ballast:
2,200 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
30.81 m²
Mainsail Area:
35.90 m²
Total Sail Area (calculated):
66.71 m²
Sail Area (reported):
66.70 m²
I (Fore Triangle Height):
15.60 m
J (Fore Triangle Base):
3.95 m
P (Mainsail Hoist):
14.65 m
E (Boom Length):
4.90 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
3YM30/SD20
Fuel Capacity:
129 L
Water Capacity:
231 L
Performance Ratios
Hull Speed:
7.75 knots
SA/Displacement (Calculated):
19.77
SA/Displacement (Reported):
20.17
Ballast/Disp Ratio:
35.48%
Displacement/Length:
162.90
Comfort Ratio:
22.95
Capsize Screening:
1.98
S-Number:
3.60
Notes
Hot water: 25l
