ANSA 42
Built by Rex Marin / Ansa Sailing AB (SWE)
• Designed by Ocke Mannerfelt
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1979
Number Built:
58
Dimensions
Length Overall (LOA):
12.67 m
Length Waterline (LWL):
10.77 m
Beam:
3.07 m
Draft (Max):
1.90 m
Weight & Ballast
Displacement:
5,851 kg
Ballast:
2,998 kg
Sail Plan
Foresail Area:
29.77 m²
Mainsail Area:
34.93 m²
Total Sail Area (calculated):
64.70 m²
Sail Area (reported):
64.66 m²
I (Fore Triangle Height):
13.20 m
J (Fore Triangle Base):
4.51 m
P (Mainsail Hoist):
14.33 m
E (Boom Length):
4.88 m
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
MD11C
Performance Ratios
Hull Speed:
7.96 knots
SA/Displacement (Calculated):
19.93
SA/Displacement (Reported):
20.32
Ballast/Disp Ratio:
51.24%
Displacement/Length:
130.59
Comfort Ratio:
24.69
Capsize Screening:
1.72
S-Number:
4.17
Notes
Draft for shoal keel vers. 5'.
