AMIGO 40
Built by Arne Arksunds (SWE)
• Designed by Carl Andersson
General Information
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1961
Number Built:
48
Dimensions
Length Overall (LOA):
9.36 m
Length Waterline (LWL):
8.00 m
Beam:
3.05 m
Draft (Max):
1.50 m
Weight & Ballast
Displacement:
5,500 kg
Ballast:
2,600 kg
Ballast Type:
Cast iron
Sail Plan
Sail Area (reported):
39.48 m²
Engine & Systems
Engine Make:
Volvo Penta
Engine Type:
Diesel
Engine Model:
2003
Fuel Capacity:
79 L
Water Capacity:
201 L
Performance Ratios
Hull Speed:
6.87 knots
SA/Displacement (Reported):
12.93
Ballast/Disp Ratio:
47.27%
Displacement/Length:
299.26
Comfort Ratio:
31.58
Capsize Screening:
1.75
Notes
The original wooden Amigo 40 was built in 1961. It is thought production of fiberglass hulls began in the 1970's. We have been told hull #19 was built in 1979.
