DIAM 24
Built by ADH Inotec,
• Designed by VPLP Design
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Trimaran Dbrd.
Rigging Type:
Frac. Sloop (Rotating Spar)
Construction:
FG sandwich UD carbon reinforcement, PVC foam
First Built:
2014
Dimensions
Length Overall (LOA):
7.24 m
Length Waterline (LWL):
7.24 m
Beam:
5.62 m
Draft (Max):
1.50 m
Max Height:
12.19 m
Weight & Ballast
Displacement:
450 kg
Sail Plan
Sail Area (reported):
32.98 m²
Engine & Systems
Performance Ratios
SA/Displacement (Reported):
57.21
Displacement/Length:
33.06
Notes
Sail area: Mainsail: 22m²/237 sq.ft.
