DEHLER 45
Built by Dehler
• Designed by Simonis Voogd
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
2010
Dimensions
Length Overall (LOA):
13.70 m
Length Waterline (LWL):
11.99 m
Beam:
3.86 m
Draft (Max):
2.20 m
Max Height:
20.85 m
Weight & Ballast
Displacement:
9,700 kg
Ballast:
3,530 kg
Sail Plan
Foresail Area:
43.27 m²
Mainsail Area:
53.52 m²
Total Sail Area (calculated):
96.79 m²
Sail Area (reported):
96.80 m²
I (Fore Triangle Height):
17.21 m
J (Fore Triangle Base):
5.03 m
P (Mainsail Hoist):
17.40 m
E (Boom Length):
6.15 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
D2-40
Engine Power:
39 HP
Fuel Capacity:
167 L
Water Capacity:
231 L
Performance Ratios
Hull Speed:
8.40 knots
SA/Displacement (Calculated):
21.28
SA/Displacement (Reported):
21.72
Ballast/Disp Ratio:
36.39%
Displacement/Length:
156.80
Comfort Ratio:
27.41
Capsize Screening:
1.83
S-Number:
3.89
Notes
Draft Racing: 2,50 m/8.2'
