CS 30
Built by Canadian Sailcraft (CAN)
• Designed by Tony Castro
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1984
Last Built:
1990
Number Built:
500
Dimensions
Length Overall (LOA):
9.14 m
Length Waterline (LWL):
7.75 m
Beam:
3.12 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
3,629 kg
Ballast:
1,560 kg
Sail Plan
Foresail Area:
23.41 m²
Mainsail Area:
19.50 m²
Total Sail Area (calculated):
42.91 m²
Sail Area (reported):
42.92 m²
I (Fore Triangle Height):
12.80 m
J (Fore Triangle Base):
3.66 m
P (Mainsail Hoist):
11.13 m
E (Boom Length):
3.51 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
2002
Engine Power:
18 HP
Fuel Capacity:
72 L
Water Capacity:
114 L
Performance Ratios
Hull Speed:
6.76 knots
SA/Displacement (Calculated):
18.17
SA/Displacement (Reported):
18.54
Ballast/Disp Ratio:
43.00%
Displacement/Length:
217.43
Comfort Ratio:
20.79
Capsize Screening:
2.05
S-Number:
2.67
Notes
This was the most popular model built by CS yachts with more than 90 built in the first year alone.
