CS 27
Built by Canadian Sailcraft (CAN)
• Designed by Raymond Wall
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1975
Last Built:
1983
Number Built:
480
Dimensions
Length Overall (LOA):
8.23 m
Length Waterline (LWL):
7.29 m
Beam:
2.84 m
Draft (Max):
1.58 m
Max Height:
11.51 m
Weight & Ballast
Displacement:
2,767 kg
Ballast:
1,089 kg
Ballast Type:
Iron /Lead
Sail Plan
Foresail Area:
18.08 m²
Mainsail Area:
13.52 m²
Total Sail Area (calculated):
31.60 m²
Sail Area (reported):
42.09 m²
I (Fore Triangle Height):
11.03 m
J (Fore Triangle Base):
3.28 m
P (Mainsail Hoist):
9.14 m
E (Boom Length):
2.96 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
YSE
Performance Ratios
Hull Speed:
6.55 knots
SA/Displacement (Calculated):
16.03
SA/Displacement (Reported):
21.78
Ballast/Disp Ratio:
39.34%
Displacement/Length:
198.97
Comfort Ratio:
19.38
Capsize Screening:
2.05
S-Number:
2.64
Notes
Reported sail area above includes a 150% genoa.
