CROWN 34
Built by Calgan Marine (CAN)
• Designed by Hein Driehuyzen
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1975
Last Built:
1979
Number Built:
30
Dimensions
Length Overall (LOA):
10.30 m
Length Waterline (LWL):
8.51 m
Beam:
3.33 m
Draft (Max):
1.80 m
Weight & Ballast
Displacement:
4,763 kg
Ballast:
2,177 kg
Sail Plan
Foresail Area:
31.07 m²
Mainsail Area:
19.65 m²
Total Sail Area (calculated):
50.72 m²
Sail Area (reported):
51.47 m²
I (Fore Triangle Height):
13.78 m
J (Fore Triangle Base):
4.51 m
P (Mainsail Hoist):
11.83 m
E (Boom Length):
3.32 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Model:
2QM15H
Engine Power:
16 HP
Fuel Capacity:
76 L
Water Capacity:
114 L
Performance Ratios
Hull Speed:
7.08 knots
SA/Displacement (Calculated):
17.92
SA/Displacement (Reported):
18.55
Ballast/Disp Ratio:
45.71%
Displacement/Length:
215.37
Comfort Ratio:
22.64
Capsize Screening:
2.00
S-Number:
2.67
Notes
After the first CROWN 34's were built, Calgan Marine sold the molds to GlassFab of Monroe, WA.,USA. A few were then manufactured and sold as the SUN 1030. Later, the molds were repossessed by Calgan and then sold to Clark Boat Co. USA. With a few modifications they were then built and sold as the SAN JUAN 34.
