CORSAIR 36 (WESTERLY)
Built by Westerly Yachts Ltd. (UK)
• Designed by Ed Dubois
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1983
Last Built:
1986
Number Built:
106
Dimensions
Length Overall (LOA):
10.87 m
Length Waterline (LWL):
9.27 m
Beam:
3.81 m
Draft (Max):
1.50 m
Weight & Ballast
Displacement:
7,031 kg
Ballast:
2,996 kg
Sail Plan
Foresail Area:
33.45 m²
Mainsail Area:
28.09 m²
Total Sail Area (calculated):
61.54 m²
Sail Area (reported):
61.50 m²
I (Fore Triangle Height):
14.63 m
J (Fore Triangle Base):
4.57 m
P (Mainsail Hoist):
12.80 m
E (Boom Length):
4.39 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
2003
Engine Power:
28 HP
Fuel Capacity:
159 L
Water Capacity:
314 L
Performance Ratios
Hull Speed:
7.39 knots
SA/Displacement (Calculated):
16.77
SA/Displacement (Reported):
17.10
Ballast/Disp Ratio:
42.61%
Displacement/Length:
245.81
Comfort Ratio:
25.91
Capsize Screening:
2.01
S-Number:
2.23
Notes
The CORSAIR was followed by the CORSAIR II (1986-1989) with nearly identical dimensions.
