ALOHA 30
Built by Ouyang Boat Works (CAN)
• Designed by Ron Holland
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1986
Last Built:
1989
Dimensions
Length Overall (LOA):
9.14 m
Length Waterline (LWL):
7.92 m
Beam:
3.05 m
Draft (Max):
1.75 m
Weight & Ballast
Displacement:
3,084 kg
Ballast:
1,343 kg
Sail Plan
Foresail Area:
17.23 m²
Mainsail Area:
23.52 m²
Total Sail Area (calculated):
40.75 m²
Sail Area (reported):
40.78 m²
I (Fore Triangle Height):
10.67 m
J (Fore Triangle Base):
3.23 m
P (Mainsail Hoist):
11.43 m
E (Boom Length):
4.11 m
Engine & Systems
Engine Make:
Westerbeke or Volvo
Engine Type:
Diesel
Fuel Capacity:
45 L
Water Capacity:
114 L
Performance Ratios
Hull Speed:
6.83 knots
SA/Displacement (Calculated):
19.23
SA/Displacement (Reported):
19.63
Ballast/Disp Ratio:
43.53%
Displacement/Length:
172.72
Comfort Ratio:
17.99
Capsize Screening:
2.11
S-Number:
3.38
Notes
Shoal draft: 4.5'
