CONCORDIA 40
Built by Abeking & Rasmussen (GER)
• Designed by C. Raymond Hunt
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Long Keel
Rigging Type:
Masthead Yawl
Construction:
Wood planked, (Mahogany, Oak frames)
First Built:
1938
Last Built:
1966
Number Built:
103
Dimensions
Length Overall (LOA):
12.14 m
Length Waterline (LWL):
8.69 m
Beam:
3.12 m
Draft (Max):
1.73 m
Weight & Ballast
Displacement:
8,165 kg
Ballast:
3,493 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
26.81 m²
Mainsail Area:
31.77 m²
Total Sail Area (calculated):
58.58 m²
Sail Area (reported):
60.39 m²
I (Fore Triangle Height):
13.03 m
J (Fore Triangle Base):
4.11 m
P (Mainsail Hoist):
11.58 m
E (Boom Length):
5.49 m
Engine & Systems
Engine Make:
Gray Marine
Engine Type:
Gas
Engine Power:
30 HP
Performance Ratios
Hull Speed:
7.15 knots
SA/Displacement (Calculated):
14.45
SA/Displacement (Reported):
15.20
Ballast/Disp Ratio:
42.78%
Displacement/Length:
347.13
Comfort Ratio:
39.29
Capsize Screening:
1.57
S-Number:
1.27
Notes
The CONCORDIA 40 is also referred to as the CONCORDIA YAWL.
