COLUMBIA T-23
Built by Columbia Yachts (USA)
• Designed by Alan Payne
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Modified Full Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1973
Last Built:
1977
Number Built:
406
Dimensions
Length Overall (LOA):
6.88 m
Length Waterline (LWL):
6.10 m
Beam:
2.41 m
Draft (Max):
0.59 m
Max Height:
8.58 m
Weight & Ballast
Displacement:
1,043 kg
Ballast:
367 kg
Ballast Type:
lead
Sail Plan
Foresail Area:
10.98 m²
Mainsail Area:
9.27 m²
Total Sail Area (calculated):
20.25 m²
Sail Area (reported):
20.25 m²
I (Fore Triangle Height):
7.87 m
J (Fore Triangle Base):
2.79 m
P (Mainsail Hoist):
6.58 m
E (Boom Length):
2.82 m
Engine & Systems
Fuel Capacity:
19 L
Water Capacity:
19 L
Performance Ratios
Hull Speed:
5.99 knots
SA/Displacement (Calculated):
19.69
SA/Displacement (Reported):
20.07
Ballast/Disp Ratio:
35.22%
Displacement/Length:
128.35
Comfort Ratio:
10.86
Capsize Screening:
2.40
S-Number:
4.17
Notes
A number of different boats from a number of builders (at least into the mid 1980's) have shared origins with this particular design.
