COLUMBIA SABRE
Built by Columbia Yachts (USA)
• Designed by Sigurd Herburn/Columbia Yachts
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin Keel
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1965
Last Built:
1968
Number Built:
143
Dimensions
Length Overall (LOA):
9.88 m
Length Waterline (LWL):
6.88 m
Beam:
1.91 m
Draft (Max):
1.32 m
Max Height:
10.95 m
Weight & Ballast
Displacement:
2,041 kg
Ballast:
1,270 kg
Sail Plan
Foresail Area:
12.65 m²
Mainsail Area:
19.06 m²
Total Sail Area (calculated):
31.71 m²
Sail Area (reported):
32.24 m²
I (Fore Triangle Height):
8.74 m
J (Fore Triangle Base):
2.90 m
P (Mainsail Hoist):
9.27 m
E (Boom Length):
4.11 m
Engine & Systems
Water Capacity:
68 L
Performance Ratios
Hull Speed:
6.37 knots
SA/Displacement (Calculated):
19.71
SA/Displacement (Reported):
20.43
Ballast/Disp Ratio:
62.22%
Displacement/Length:
174.50
Comfort Ratio:
23.70
Capsize Screening:
1.52
S-Number:
3.41
Notes
The COLUMBIA SABRE hull is from a mold taken off an Int. 5.5 meter class racer (circa 1958). Columbia first built a small number of these as one-design racers. (The international 5.5 class ruled that they did not conform to their specifications and were banned from class events.) Later Columbia created this version with a trunk cabin and some cruising amenities which is called the SABRE. A similar model (SCORPION 32) was also built by Ericson Yachts, probably from this same mold.
