COLUMBIA 9.6
Built by Columbia Yachts (USA)
• Designed by Alan Payne
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1975
Last Built:
1979
Number Built:
150
Dimensions
Length Overall (LOA):
9.60 m
Length Waterline (LWL):
7.24 m
Beam:
3.10 m
Draft (Max):
1.68 m
Weight & Ballast
Displacement:
4,627 kg
Ballast:
2,041 kg
Sail Plan
Foresail Area:
24.53 m²
Mainsail Area:
17.93 m²
Total Sail Area (calculated):
42.46 m²
Sail Area (reported):
42.46 m²
I (Fore Triangle Height):
12.24 m
J (Fore Triangle Base):
4.01 m
P (Mainsail Hoist):
10.70 m
E (Boom Length):
3.35 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
MD7A
Fuel Capacity:
76 L
Water Capacity:
151 L
Performance Ratios
Hull Speed:
6.53 knots
SA/Displacement (Calculated):
15.29
SA/Displacement (Reported):
15.60
Ballast/Disp Ratio:
44.12%
Displacement/Length:
339.91
Comfort Ratio:
27.52
Capsize Screening:
1.88
S-Number:
1.37
Notes
Designed to rate at the half ton level under the IOR rule.
