COLUMBIA 7.6
Built by Whittaker Corp./Hughes Boat Works/Aura Yachts
• Designed by Alan Payne
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/transom hung rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1976
Last Built:
1986
Dimensions
Length Overall (LOA):
7.64 m
Length Waterline (LWL):
6.30 m
Beam:
2.80 m
Draft (Max):
1.07 m
Weight & Ballast
Displacement:
2,041 kg
Ballast:
680 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
16.40 m²
Mainsail Area:
12.75 m²
Total Sail Area (calculated):
29.15 m²
Sail Area (reported):
29.17 m²
I (Fore Triangle Height):
10.06 m
J (Fore Triangle Base):
3.26 m
P (Mainsail Hoist):
8.53 m
E (Boom Length):
2.99 m
Engine & Systems
Water Capacity:
61 L
Performance Ratios
Hull Speed:
6.09 knots
SA/Displacement (Calculated):
18.12
SA/Displacement (Reported):
18.48
Ballast/Disp Ratio:
33.33%
Displacement/Length:
227.48
Comfort Ratio:
16.52
Capsize Screening:
2.22
S-Number:
2.55
Notes
A Yanmar diesel was offered as an option.
