COLUMBIA 57
Built by Columbia Yachts (USA)
• Designed by William Tripp Jr.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1969
Last Built:
1974
Number Built:
11
Dimensions
Length Overall (LOA):
17.22 m
Length Waterline (LWL):
12.40 m
Beam:
3.96 m
Draft (Max):
2.44 m
Weight & Ballast
Displacement:
20,412 kg
Ballast:
9,979 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
64.18 m²
Mainsail Area:
55.93 m²
Total Sail Area (calculated):
120.11 m²
Sail Area (reported):
120.12 m²
I (Fore Triangle Height):
19.14 m
J (Fore Triangle Base):
6.71 m
P (Mainsail Hoist):
17.07 m
E (Boom Length):
6.55 m
Engine & Systems
Performance Ratios
Hull Speed:
8.55 knots
SA/Displacement (Calculated):
16.08
SA/Displacement (Reported):
16.42
Ballast/Disp Ratio:
48.89%
Displacement/Length:
298.64
Comfort Ratio:
50.29
Capsize Screening:
1.47
S-Number:
1.71
Notes
First introduced as a racer with trim tab (as shown here). Later boats were turned out with more cruising amenities. Some were even rigged as schooners. An unknown number were sold as the SAILCRAFTER 57. The COLUMBIA 56 (Motor sailor), introduced in 1974, came from this same hull mold.
