COLUMBIA 50
Built by Columbia Yachts (USA)
• Designed by William Tripp Jr.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1965
Last Built:
1972
Number Built:
62
Dimensions
Length Overall (LOA):
15.24 m
Length Waterline (LWL):
10.13 m
Beam:
3.67 m
Draft (Max):
1.99 m
Weight & Ballast
Displacement:
14,515 kg
Ballast:
6,622 kg
Sail Plan
Foresail Area:
46.33 m²
Mainsail Area:
44.61 m²
Total Sail Area (calculated):
90.94 m²
Sail Area (reported):
90.95 m²
I (Fore Triangle Height):
16.79 m
J (Fore Triangle Base):
5.52 m
P (Mainsail Hoist):
14.78 m
E (Boom Length):
6.04 m
Engine & Systems
Engine Make:
Universal
Engine Type:
Diesel
Engine Power:
70 HP
Performance Ratios
Hull Speed:
7.73 knots
SA/Displacement (Calculated):
15.28
SA/Displacement (Reported):
15.61
Ballast/Disp Ratio:
45.63%
Displacement/Length:
388.62
Comfort Ratio:
47.05
Capsize Screening:
1.52
S-Number:
1.11
Notes
When introduced in 1965, the COLUMBIA 50 was the largest production fiberglass sailboat available in the US.
