COLUMBIA 45
Built by Columbia Yachts (USA)
• Designed by William Tripp Jr.
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin with rudder on skeg
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1971
Last Built:
1976
Number Built:
180
Dimensions
Length Overall (LOA):
13.79 m
Length Waterline (LWL):
10.52 m
Beam:
3.76 m
Draft (Max):
2.21 m
Weight & Ballast
Displacement:
11,340 kg
Ballast:
4,672 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
37.42 m²
Mainsail Area:
27.45 m²
Total Sail Area (calculated):
64.87 m²
Sail Area (reported):
64.85 m²
I (Fore Triangle Height):
13.72 m
J (Fore Triangle Base):
5.46 m
P (Mainsail Hoist):
11.26 m
E (Boom Length):
4.88 m
Engine & Systems
Engine Make:
Perkins
Engine Type:
Diesel
Engine Model:
4-236
Engine Power:
85 HP
Fuel Capacity:
500 L
Water Capacity:
454 L
Performance Ratios
Hull Speed:
7.87 knots
SA/Displacement (Calculated):
12.85
SA/Displacement (Reported):
13.11
Ballast/Disp Ratio:
41.20%
Displacement/Length:
271.79
Comfort Ratio:
36.09
Capsize Screening:
1.69
S-Number:
1.61
Notes
Raised deck motor sailer was available in full keel and shoal draft versions. A ketch rig was also available.
