CNB 66
Built by CNB (FRA)
• Designed by Philippe Briand/Jean-Marc Platon
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Cutter
Construction:
FG
First Built:
2018
Dimensions
Length Overall (LOA):
20.61 m
Length Waterline (LWL):
18.45 m
Beam:
5.51 m
Draft (Max):
2.95 m
Max Height:
28.76 m
Weight & Ballast
Displacement:
31,100 kg
Ballast:
9,350 kg
Sail Plan
Foresail Area:
95.86 m²
Mainsail Area:
94.11 m²
Total Sail Area (calculated):
189.97 m²
Sail Area (reported):
214.88 m²
I (Fore Triangle Height):
25.00 m
J (Fore Triangle Base):
7.67 m
P (Mainsail Hoist):
24.13 m
E (Boom Length):
7.80 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
D4
Engine Power:
180 HP
Fuel Capacity:
1,298 L
Water Capacity:
999 L
Performance Ratios
Hull Speed:
10.43 knots
SA/Displacement (Calculated):
19.21
SA/Displacement (Reported):
22.20
Ballast/Disp Ratio:
30.06%
Displacement/Length:
138.02
Comfort Ratio:
35.85
Capsize Screening:
1.77
S-Number:
3.94
Notes
LOA = with anchor davit
