CLIPPER MARINE 23
Built by Clipper Marine (USA)
• Designed by William Crealock
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Swing Keel
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1976
Dimensions
Length Overall (LOA):
6.91 m
Length Waterline (LWL):
5.72 m
Beam:
2.34 m
Draft (Max):
1.37 m
Draft (Min):
0.16 m
Weight & Ballast
Displacement:
919 kg
Ballast:
227 kg
Ballast Type:
Iron
Sail Plan
Foresail Area:
10.38 m²
Mainsail Area:
8.92 m²
Total Sail Area (calculated):
19.30 m²
Sail Area (reported):
19.32 m²
I (Fore Triangle Height):
7.54 m
J (Fore Triangle Base):
2.75 m
P (Mainsail Hoist):
6.50 m
E (Boom Length):
2.74 m
Engine & Systems
Performance Ratios
Hull Speed:
5.80 knots
SA/Displacement (Calculated):
20.42
SA/Displacement (Reported):
20.84
Ballast/Disp Ratio:
24.69%
Displacement/Length:
137.14
Comfort Ratio:
10.41
Capsize Screening:
2.43
S-Number:
4.12
Notes
After Clipper Marine went out of business, a twin keel version (CLIPPER 23) was built in Canada (Sawyer Marine 1984-?).
