CIRRUS 22 (WESTERLY)
Built by Westerly Marine Ltd. (UK)
• Designed by John Butler
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
1968
Last Built:
1972
Number Built:
398
Dimensions
Length Overall (LOA):
6.71 m
Length Waterline (LWL):
5.79 m
Beam:
2.44 m
Draft (Max):
1.07 m
Weight & Ballast
Displacement:
1,470 kg
Ballast:
660 kg
Sail Plan
Foresail Area:
10.47 m²
Mainsail Area:
11.15 m²
Total Sail Area (calculated):
21.62 m²
Sail Area (reported):
21.65 m²
I (Fore Triangle Height):
7.92 m
J (Fore Triangle Base):
2.64 m
P (Mainsail Hoist):
8.13 m
E (Boom Length):
2.74 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel
Engine Model:
MD1
Fuel Capacity:
26 L
Performance Ratios
Hull Speed:
5.84 knots
SA/Displacement (Calculated):
16.72
SA/Displacement (Reported):
17.07
Ballast/Disp Ratio:
44.91%
Displacement/Length:
210.88
Comfort Ratio:
15.76
Capsize Screening:
2.17
S-Number:
2.59
Notes
The diesel inboard was an option.
