CHOATE 40
Built by Dennis Choate (USA)
• Designed by Scott Kaufman
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
1979
Dimensions
Length Overall (LOA):
11.99 m
Length Waterline (LWL):
9.53 m
Beam:
3.83 m
Draft (Max):
2.07 m
Weight & Ballast
Displacement:
5,761 kg
Ballast:
3,357 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
39.17 m²
Mainsail Area:
27.59 m²
Total Sail Area (calculated):
66.76 m²
Sail Area (reported):
66.98 m²
I (Fore Triangle Height):
15.79 m
J (Fore Triangle Base):
4.96 m
P (Mainsail Hoist):
13.72 m
E (Boom Length):
4.02 m
Engine & Systems
Performance Ratios
Hull Speed:
7.49 knots
SA/Displacement (Calculated):
20.77
SA/Displacement (Reported):
21.27
Ballast/Disp Ratio:
58.27%
Displacement/Length:
185.78
Comfort Ratio:
20.04
Capsize Screening:
2.16
S-Number:
3.37
