CHATAM 40
Built by Various
• Designed by Gilbert Caroff
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Swing Keel
Rigging Type:
Cutter
Construction:
Aluminum or steel
First Built:
1994
Dimensions
Length Overall (LOA):
12.55 m
Length Waterline (LWL):
11.28 m
Beam:
4.20 m
Draft (Max):
2.40 m
Draft (Min):
0.90 m
Headroom:
2.00 m
Weight & Ballast
Displacement:
12,050 kg
Ballast:
3,850 kg
Sail Plan
Sail Area (reported):
95.00 m²
Engine & Systems
Engine Type:
Diesel
Engine Power:
25 to 50 HP
Fuel Capacity:
400 L
Water Capacity:
800 L
Performance Ratios
Hull Speed:
8.15 knots
SA/Displacement (Reported):
18.45
Ballast/Disp Ratio:
31.95%
Displacement/Length:
233.95
Comfort Ratio:
32.62
Capsize Screening:
1.85
Notes
Also available with sloop rig.
