CENTURION 40S
Built by Wauquiez
• Designed by Berret/Racoupeau
Market Value
No pricing data available yet.
Help the community by adding price information you know about this model.
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
Construction:
FG w/balsa core
First Built:
2003
Last Built:
2007
Number Built:
106
Dimensions
Length Overall (LOA):
12.35 m
Length Waterline (LWL):
11.11 m
Beam:
3.85 m
Draft (Max):
2.30 m
Draft (Min):
1.85 m
Weight & Ballast
Displacement:
8,600 kg
Ballast:
2,700 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
32.33 m²
Mainsail Area:
44.25 m²
Total Sail Area (calculated):
76.58 m²
Sail Area (reported):
76.55 m²
I (Fore Triangle Height):
15.69 m
J (Fore Triangle Base):
4.12 m
P (Mainsail Hoist):
15.00 m
E (Boom Length):
5.90 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
55 HP
Fuel Capacity:
220 L
Water Capacity:
401 L
Performance Ratios
Hull Speed:
8.09 knots
SA/Displacement (Calculated):
18.24
SA/Displacement (Reported):
18.61
Ballast/Disp Ratio:
31.39%
Displacement/Length:
174.78
Comfort Ratio:
26.55
Capsize Screening:
1.90
S-Number:
3.23
Notes
Shoal draft: 6.07'/1.85m
