ALERION EXPRESS 38
Built by Tillotson Pearson Inc, (USA)
• Designed by Carl Schumacher
General Information
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Masthead Yawl
Construction:
FG
First Built:
1997
Number Built:
8
Dimensions
Length Overall (LOA):
11.66 m
Length Waterline (LWL):
9.17 m
Beam:
3.28 m
Draft (Max):
1.80 m
Max Height:
17.15 m
Weight & Ballast
Displacement:
5,897 kg
Ballast:
2,722 kg
Ballast Type:
Lead
Sail Plan
Foresail Area:
28.22 m²
Mainsail Area:
32.38 m²
Total Sail Area (calculated):
60.60 m²
Sail Area (reported):
75.25 m²
I (Fore Triangle Height):
13.23 m
J (Fore Triangle Base):
4.27 m
P (Mainsail Hoist):
13.53 m
E (Boom Length):
4.79 m
Engine & Systems
Engine Make:
Volvo
Engine Type:
Diesel; Saildrive
Engine Power:
40 HP
Fuel Capacity:
98 L
Water Capacity:
170 L
Performance Ratios
Hull Speed:
7.35 knots
SA/Displacement (Calculated):
18.57
SA/Displacement (Reported):
23.52
Ballast/Disp Ratio:
46.15%
Displacement/Length:
213.24
Comfort Ratio:
26.12
Capsize Screening:
1.83
S-Number:
2.76
Notes
Also available with fractional sloop rig.
