ALERION EXPRESS 19
Built by Tillotson Pearson Inc, (USA)
• Designed by Garry Hoyt
General Information
Hull Type:
Keel/Cbrd.
Rigging Type:
Cat (unstayed)
Construction:
FG
First Built:
1998
Dimensions
Length Overall (LOA):
5.84 m
Length Waterline (LWL):
5.77 m
Beam:
2.64 m
Draft (Max):
1.27 m
Draft (Min):
0.30 m
Weight & Ballast
Displacement:
794 kg
Ballast:
136 kg
Sail Plan
Engine & Systems
Performance Ratios
Hull Speed:
5.83 knots
Ballast/Disp Ratio:
17.14%
Displacement/Length:
115.35
Comfort Ratio:
8.02
Capsize Screening:
2.88
