CATALINA 350
Built by Catalina Yachts (USA)
• Designed by Gerry Douglas
General Information
Hull Type:
Fin w/spade rudder
Rigging Type:
Masthead Sloop
Construction:
FG
First Built:
2003
Dimensions
Length Overall (LOA):
10.80 m
Length Waterline (LWL):
9.53 m
Beam:
3.96 m
Draft (Max):
2.03 m
Weight & Ballast
Displacement:
5,868 kg
Ballast:
2,330 kg
Sail Plan
Foresail Area:
31.31 m²
Mainsail Area:
25.66 m²
Total Sail Area (calculated):
56.97 m²
Sail Area (reported):
56.86 m²
I (Fore Triangle Height):
14.25 m
J (Fore Triangle Base):
4.40 m
P (Mainsail Hoist):
12.47 m
E (Boom Length):
4.11 m
Engine & Systems
Engine Make:
Yanmar
Engine Type:
Diesel
Engine Power:
30 HP
Fuel Capacity:
148 L
Water Capacity:
333 L
Performance Ratios
Hull Speed:
7.49 knots
SA/Displacement (Calculated):
17.51
SA/Displacement (Reported):
17.83
Ballast/Disp Ratio:
39.71%
Displacement/Length:
188.89
Comfort Ratio:
20.22
Capsize Screening:
2.22
S-Number:
2.95
Notes
Draft for wing keel version: 1.37m/4.5'
