CATALINA 18
Built by Catalina Yachts (USA)
• Designed by Catalina Yachts
General Information
Hull Type:
Wing Keel
Rigging Type:
Fractional Sloop
Construction:
FG
First Built:
2000
Dimensions
Length Overall (LOA):
5.49 m
Length Waterline (LWL):
4.98 m
Beam:
2.31 m
Draft (Max):
0.71 m
Max Height:
7.06 m
Weight & Ballast
Displacement:
680 kg
Ballast:
193 kg
Sail Plan
Foresail Area:
6.04 m²
Mainsail Area:
8.00 m²
Total Sail Area (calculated):
14.04 m²
Sail Area (reported):
14.40 m²
I (Fore Triangle Height):
6.10 m
J (Fore Triangle Base):
1.98 m
P (Mainsail Hoist):
6.17 m
E (Boom Length):
2.59 m
Engine & Systems
Performance Ratios
Hull Speed:
5.41 knots
SA/Displacement (Calculated):
18.14
SA/Displacement (Reported):
18.97
Ballast/Disp Ratio:
28.33%
Displacement/Length:
153.77
Comfort Ratio:
9.27
Capsize Screening:
2.65
S-Number:
3.52
Notes
Originally called CAPRI 18. (before 2000).
